LinkQnet RJ45 CAT6 Single Wall Mount Surface Box

Summary: LinkQnet RJ45 CAT6 Single Wall Mount Surface Box is a compact and durable network solution. It features a single RJ45 port supporting CAT6 cables with up to 250MHz bandwidth, ensuring fast and stable internet connections. Easy to install on walls, it’s perfect for home or office networking setups that require reliable wired connectivity.

LinkQnet RJ45 CAT6 Single Wall Mount Surface Box – RJ45 Port, CAT 6, 250MHz Bandwidth

Product Overview

The LinkQnet RJ45 CAT6 Single Wall Mount Surface Box features a white, compact design with dimensions 50×65.8×25 mm for easy wall installation. It supports CAT6 UTP cables (AWG 24-22) with a max bandwidth of 250 MHz, ensuring high-speed signal transmission. Equipped with an RJ45 female (8P8C) connection for one device, it offers reliable network connectivity with secure screw assembly.

Features

•For tool-free assembly by solderless, screwless and stripping-free connection technology IDC mounting)
•Patch panel incl. fixing screws for mounting on wall and desktop
•CAT 6 distributor for cable diameters of up to 7.0 mm (AWG 22-24)
•With a clear plastic display to label the individual connections for a perfect cable management.
•1-port patch panel with RJ45 socket for connecting an terminated CAT 6 network cabl

Specifications

•Product Code: CAT6WALL-LQ
•Description: LinkQnet RJ45 CAT6 Single Wall Mount Surface Box
•Connection Type: RJ45 female (8P8C)
•Device Connections: 1
Cable
•Specification: CAT 6
•Shielding class: UTP
•AWG: 24-22
•Signal transmission
•max. bandwidth: 250 MHz
General
•Color: White
•Width: 50 mm
•Height: 65.8 mm
•Depth: 25 mm
•Consumption Unit: 1 pc
•Assembly Material: screws
