AMD Ryzen 5 8500G Desktop Processor

AMD Ryzen 5 8500G Desktop Processor – Ryzen 8000 Series, Desktop Form Factor, 2 x Zen 4, 4 x Zen 4c Architecture, 6 Cores, Multithreading, 12 Threads, Up to 5GHz Max Boost Clock, 3.5GHz Base Clock, 6MB L2 Cache, 16MB L3 Cache, 65W Default TDP, AM5 CPU Socket, AMD Radeon 740M Graphics, 2800MHz Graphics Frequency, Retail Box, No Warranty.

Product Overview

The AMD Ryzen 5 8500G is a 6-core/12-thread AM5 APU built on TSMC 4nm, combining 2× Zen 4 and 4× Zen 4c cores with up to 5 GHz boost and 65 W TDP. It integrates Radeon 740M graphics (4 CUs at 2.8 GHz) with HDMI 2.1 and DisplayPort 2.1 outputs, supporting up to four displays and modern codecs including AV1 encode/decode. With DDR5-5200 support, PCIe 4.0 lanes, USB 4 and USB 3.2 Gen 2 connectivity, and features like EXPO memory overclocking and Precision Boost, it is optimized for compact, graphics-capable desktop builds.

Specifications

•Product Code: 100-100000931BOX
•Description: AMD Ryzen™ 5 8500G Desktop Processor
•Family: Ryzen
•Series: Ryzen 8000 Series
•Form Factor: Desktops
•Regional Availability: Global
•Processor Architecture: 2x Zen 4 , 4x Zen 4c
•# of CPU Cores: 6
•Multithreading (SMT): Yes
•# of Threads: 12
•Max. Boost Clock : Up to 5 GHz
•Max Zen4c Clock : Up to 3.7 GHz
•Base Clock : 3.5 GHz
•Zen4 Base Clock: 4.1 GHz
•Zen4c Base Clock: 3.3 GHz
•L2 Cache: 6 MB
•L3 Cache: 16 MB
•Default TDP: 65W
•AMD Configurable TDP (cTDP): 45-65W
•Processor Technology for CPU Cores: TSMC 4nm FinFET
•CPU Compute Die (CCD) Size: 137mm²
•Package Die Count: 1
•AMD EXPO™ Memory Overclocking Technology: Yes
•Precision Boost Overdrive: Yes
•Curve Optimizer Voltage Offsets: Yes
•AMD Ryzen™ Master Support: Yes
•CPU Socket: AM5
•Supporting Chipsets: A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
•CPU Boost Technology: Precision Boost 2
•Instruction Set: x86-64
•Supported Extensions: AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
•Max. Operating Temperature (Tjmax): 95°C
•OS Support: Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

Connectivity
•Native USB 4 (40Gbps): 2
•Native USB 3.2 Gen 2 (10Gbps): 2
•Native USB 2.0 (480Mbps): 1
•PCI Express® Version: PCIe® 4.0
•Native PCIe® Lanes (Total/Usable): 14 , 10
•NVMe Support: Boot , RAID0 , RAID1
•System Memory Type: DDR5
•Memory Channels: 2
Max Memory Size by Type
•DDR5 96 GB
•LPDDR5 64 GB
•System Memory Subtype: UDIMM
Max Memory Speed
•2x1R DDR5-5200
•2x2R DDR5-5200
•4x1R DDR5-3600
•4x2R DDR5-3600
•ECC Support: Yes (Requires platform support)

•Graphics Model: AMD Radeon™ 740M
•Graphics Core Count: 4
•Graphics Frequency: 2800 MHz
•DirectX® Version: 12
•DisplayPort™ Version: 2.1
•DisplayPort Extensions: Adaptive-Sync , HDR Metadata , UHBR10
•DisplayPort Max Refresh Rates (SDR): 7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz
•DisplayPort Max Refresh Rates (HDR): 7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz
•HDMI® Version: 2.1
•HDCP Version Supported: 2.3
•USB Type-C® DisplayPort™ Alternate Mode: Yes
•Multi-Monitor Support: Yes
•Max Displays: 4
•AMD FreeSync™: Yes
•Wireless Display: Miracast
